Lower Paper Horizontal Packaging Machine
Horizontal packaging machine is mainly used for biscuits, cakes, hardware, and other products that need independent packaging. It is a semi-automatic manual feeding machine. It is economical and easy to operate. It is very popular in production plants.
- Dual transducers control and bag length can be let and cut in one step.
- High-sensitivity electrical eye traces and sealing position is input numerically for accuracy.
- Positioned stop function without sticking knife and wasting film.
- AII control is realized through software. easy for adjusting and technical upgrading.
- Simple driving system, reliable working, convenient maintenance.
Parameter
SK-W250X
| Packaging Film Width | 250mm | |||||
| Bag Style | Pillow bag | |||||
| Bag Length | 65-190mm or 120-180mm | |||||
| Bag Width | 30-110mm | |||||
| Max Outer Diameter of Coil | Max.320mm | |||||
| Packing Speed | 40-230bags / min | |||||
| Packaging Film Thickness | 0.04-0.08mm | |||||
| Power Specifications | 220V, 50Hz / 60Hz, 2.4kW | |||||
| Product Height | Max.40mm | |||||
SK-W350X
| Packaging Film Width | 350mm | |||||
| Bag Style | Pillow bag | |||||
| Bag Length | 65-190mm or 120-180mm | |||||
| Bag Width | 50-160mm | |||||
| Max Outer Diameter of Coil | Max.320mm | |||||
| Packing Speed | 40-230bags / min | |||||
| Packaging Film Thickness | 0.04-0.08mm | |||||
| Power Specifications | 220V, 50Hz / 60Hz, 2.8kW | |||||
| Product Height | Max.40mm | |||||
SK-W450X
| Packaging Film Width | 450mm | |||||
| Bag Style | Pillow bag | |||||
| Bag Length | 180-450mm | |||||
| Bag Width | 50-160mm | |||||
| Max Outer Diameter of Coil | Max.320mm | |||||
| Packing Speed | 30-120bags / min | |||||
| Packaging Film Thickness | 0.04-0.08mm | |||||
| Power Specifications | 220V, 50Hz / 60Hz, 2.8kW | |||||
| Product Height | Max.80mm | |||||
SK-W600X
| Packaging Film Width | 600mm | |||||
| Bag Style | Pillow bag | |||||
| Bag Length | 180-450mm | |||||
| Bag Width | 90-220mm | |||||
| Max Outer Diameter of Coil | Max.320mm | |||||
| Packing Speed | 30-120bags / min | |||||
| Packaging Film Thickness | 0.04-0.08mm | |||||
| Power Specifications | 220V, 50Hz / 60Hz, 2.8kW | |||||
| Product Height | Max.80mm | |||||
Application
SK-W250X/SK-W350X
| Packaging Format Range | Adjustment Method | Packing Way | Packing Speed Range | Special Process | |
| Baking | Single product packages | Display control | Back seal | 40-230bags / min | Filling nitrogen |
| Vegetables | Multiple packages | Display control | Back seal | 40-230bags / min | Three servo control |
| Plastic | Multiple packages | Display control | Back seal | 40-230bags / min | None |
| Candy | Single product packages | Display control | Back seal | 40-230bags / min | Needing vibrating plate |
| Hardware | Single product packages | Display control | Back seal | 40-230bags / min | None |
| Frozen | Multiple packages | Display control | Back seal | 40-230bags / min | With tray |
SK-W450X/SK-W600X
| Packaging Format Range | Adjustment Method | Packing Way | Packing Speed Range | Special Process | |
| Baking | Single product packages | Display control | Back seal | 30-120bags / min | Filling nitrogen |
| Vegetables | Multiple packages | Display control | Back seal | 30-120bags / min | Three servo control |
| Plastic | Multiple packages | Display control | Back seal | 30-120bags / min | None |
| Candy | Single product packages | Display control | Back seal | 30-120bags / min | Needing vibrating plate |
| Hardware | Single product packages | Display control | Back seal | 30-120bags / min | None |
| Frozen | Multiple packages | Display control | Back seal | 30-120bags / min | With tray |
