Automatic Vertical Packaging Machine
This is a small vertical packaging machine with a small size, small footprint, and economical price, mainly for the packaging of small bags of granular products.
- This machine is small, low noise and economical.
- Adopt a photoelectric eye control system, a stepper motor to pull the film, stable and reliable performance, and low noise.
- This machine is available in electric and pneumatic versions.
- This one can choose different measurement methods.
- The equipment is small, occupies a small area, and is easy to move. The main components are made of stainless steel. The appearance is beautiful and meets the national food hygiene standards.
Parameter
Air Consumption | 0.65mpa, 2.5m3 / min.6kg / cm2 | |||||
Packaging Film Width | 320mm | |||||
Bag Style | Pillow bag | |||||
Bag Length | 50-200mm | |||||
Bag Width | 30-150mm | |||||
Max Outer Diameter of Coil | Max.360mm | |||||
Packing Speed | 30-90bags / min | |||||
Packaging Film Thickness | 0.04-0.08mm | |||||
Power Specifications | 220V.50 / 60Hz.2.8Kw | |||||
Packing Dimension (L*W*H) | (L)2080*(W)700*(H)1900mm | |||||
Packaging Materials | Composite film | |||||
Total Power | 2.2KW | |||||
Overall Weight | 300kg |
Application
Packaging Format Range | Adjustment Method | Packing Way | Packing Speed Range | Special Process | |
Puffed | 5-20g | Display control | Measuring cup | 30-60bags / min | Air filling |
Dried Fruits / Nuts | 5-50g | Display control | Measuring cup / Multi-head Combination Scale | 20-60bags / min | Bag exhaust |
Fertilizers | 5-100g | Display control | Measuring cup | 20-60bags / min | Open-closed door |
Feed | 5-100g | Display control | Measuring cup | 20-60bags / min | Open-closed door |
Grains | 5-100g | Display control | Measuring cup/Linear scale | 20-60bags / min | Bag exhaust |
Hardware | 1-20pcs | Display control | Counting Vibrating Disc | 10-50bags / min | Customized Disc |
Scented Tea | 1-10g | Display control | Scented tea scale | 10-35bags / min | None |
